Introduction:
Greetings! It is my pleasure to introduce our Half Side Wrapping Machine, a high-quality packaging solution that is designed to make the transportation of large and bulky goods a breeze. The Half Side Wrapping Machine is a top-of-the-range machine, produced with the best materials available and cutting-edge technology, that makes product packaging quicker, easier, and more efficient.
Why Choose the Half Side Wrapping Machine?
The Half Side Wrapping Machine is a versatile tool that is suitable for packaging products that are of varying shapes and sizes. It is an ideal tool for companies that specialize in transportation services, courier services, warehouses, and other industries that require the efficient and timely delivery of products.
Features of the Half Side Wrapping Machine:
1. High Efficiency
The Half Side Wrapping Machine is designed to streamline your packaging process for improved efficiency. It is an automated machine that can wrap up to 40 pallets per hour, which means you can package and ship more products in less time than traditional manual wrapping methods.
2. Simple to Use
Our Half Side Wrapping Machine operates with user-friendly controls, enabling even new workers to use it with ease. The controls are intuitive and easy to understand, and the machine itself is designed with a simple structure that is easy to maintain.
3. Effective Stretch Wrapping
The Half Side Wrapping Machine is an expert in wrapping large, bulky items. It can stretch wrap products of varying sizes and shapes quickly and easily, leaving no unsecured or exposed areas.
4. Safe and Secure
The Half Side Wrapping Machine is built with strict safety standards and materials, to ensure the safety of both workers and products. It features an emergency stop button that can stop the machine in case of any unforeseen complications.
5. Standalone or Integrated
The Half Side Wrapping Machine can work standalone or be integrated into your existing packaging line. Regardless of the setup, it will always provide efficient and reliable results.
Benefits of Half Side Wrapping Machine:
1. Enhanced Productivity
The Half Side Wrapping Machine can wrap a large volume of goods in a short period, allowing you to transport more products in less time. This improves customer satisfaction, reduces shipping time frames and builds a good reputation for your company.
2. Cost-effective
Using our Half Side Wrapping Machine increases the efficiency of your business, and this translates to cost savings. It reduces labor and material costs, and improves the speed of the production process.
3. Reduced Product Damage
The Half Side Wrapping Machine provides safe and secure wrapping of products, which protects them from external damage during transportation. Its sturdiness and durability ensure that the products arrive at their intended destination in excellent condition.
Conclusion:
The Half Side Wrapping Machine is an essential tool for any business that values efficiency, productivity, and cost-effective solutions. With its easy-to-use controls, effective stretch wrapping, and high-tech automation, it helps to streamline your packaging process and increases your overall output. Lastly, as a reputable manufacturer in China, we guarantee product quality and support for each of our clients. Contact us today, and let's take your product packaging process to a whole new level.
Half-cut wrapping machine parameter description
Appearance drawing of half-cut wrapping machine
Specifications and models of half-cut wrapping machine
Main model: BBZ400-A—BBZ600-A
Main uses and features of half-cut wrapping machine
Mainly used for wrapping polyester insulating tapes, water blocking tapes, PVC tapes, non-woven tapes, paper tapes, etc. for control cables and power cables; wrapping tension is controlled by mechanical friction tapes; half-cut wrapping machines can be combined with pay-off machines , wire take-up machine, copper tape shielding machine, steel tape armoring machine and crawler tractor make up the production line; each part of the production line can be controlled independently by the motor or through the linkage control of the transmission shaft; the operation method is the human-machine interface touch screen; the main shaft bearing adopts domestic high-quality bearings.
Equipment production line composition
1. Pay-off machine
2. Copper tape shielding machine (optional)
3. Steel tape armoring machine (optional)
4. Half cutting and wrapping machine
5. Meter counting device
6. Tractor
7. Rewinding and arranging machine
8. Transmission system and electrical system
The main technical parameters
Type | BBZ400 | BBZ520 | BBZ600 |
Axis RPM | 600RPM/min | 500RPM/min | 400RPM/min |
Before Wrapping cable dia. | ≤Φ30mm | ≤Φ260mm | ≤Φ280mm |
Lapping Pitch | 15~ 150mm electronic control stepless adjustment | 15~ 150mm electronic control stepless adjustment | 15~ 200mm electronic control stepless adjustment |
Tape wide | 20~50mm | 20~50mm | 20~60mm |
Tape Axis Number | 2 discs | ||
Tape dia. | MAXΦ400mm disc diameter XΦ75mm shaft hole | MAXΦ520mm disc diameter XΦ75mm shaft hole | MAXΦ600mm disc diameter XΦ75mm shaft hole |
Tension | 0.5~5dan, with tension feedback function | ||
Tape break detection | Tape break & NO Tape Automatic Stop | ||
Braking type | Pneumatic brake | ||
The motor power | 4KW | 5.5KW | 7.5KW |
Why choose us?
- Our Armoring Machines are built to last and require minimal maintenance.
- The company has been constantly strengthening its own market competition capacity building, in the process of management innovation, continuous improvement of corporate standards, always adhere to the "customer first, quality first" business philosophy.
- Our Armoring Machines are designed to be energy-efficient.
- With our leading technology at the same time as our spirit of innovation, mutual cooperation, benefits and growth, we're going to build a prosperous future together with your esteemed firm for Half Side Wrapping Machine.
- We offer a range of customized solutions to meet the needs of our clients.
- We regard talents as the core competitiveness of our company, and attract more excellent talents by establishing a broad space for career development, excellent environment for growth of talents, and effective incentive and restraint mechanism.
- We have a strong reputation for delivering high-quality products at a competitive price.
- Our company continuously optimizes organizational capabilities and management models, takes it as our responsibility to enhance the influence of national independent brands in the Half Side Wrapping Machine industry, and promotes sustainable and rapid development.
- Our Armoring Machines come with clear instructions for easy installation and use.
- Our company adheres to the enterprise tenet of survival by quality and development by reputation and constantly develops Half Side Wrapping Machine of different grades and prices to meet the needs of buyers at different levels.
